General Properties
Product group - Hob
Brand - Bosch
Product name/family - Cooking zone ceramic
Product name / Commercial code - PIN675N17E
EAN code - 4,242,002,736,587
Built-in / Free-standing - Built-in
Installation typology - Half-integrated
Energy input - Electric
Number of gas burners - 0
Number of electric cooking zones - 4
Number of electric plates - 0
Number of radiant plates - 0
Number of halogen plates - 0
Number of induction plates - 4
Location of control panel - Hob front
Type of control setting devices - Precise Timer
Basic surface material - Ceramic
Color of surface - Black, Stainless steel
Type of frame - Facette fro+rear,side profiles
Color of frame - Stainless steel
Electrical connection rating (W) - 7,200 W
Voltage (V) - 220-240 V
Frequency (Hz) - 50; 60 Hz
Approval certificates - AENOR, CE
Length electrical supply cord (m) - 110.0 cm
Plug type - No plug
Required niche size for installation (HxWxD) - 51 x 560 x 500-490 mm
Width of the product (mm) - 606 mm
Dimensions of the product (mm) - x 606 x 527 mm
Net weight (kg) - 14.000 kg
Gross weight (kg) - 15.000 kg
Location of 1st heating element - front left
Type of 1st heating element - Induction heating, Vector zone
Dimension of 1st heating element (mm) - 196 ; 234 mm
Location of 2nd heating element - back left
Type of 2nd heating element - Induction heating, Vector zone
Dimension of 2nd heating element (mm) - 196; 234 mm
Power of 2nd heating element (kW) - 3.3 kW
Location of 3rd heating element - back right
Type of 3rd heating element - Induction heating
Dimension of 3rd heating element (mm) - 145 mm
Power of 3rd heating element (kW) - 1.4 kW
Location of 4th heating element - Cooking zone front right
Type of 4th heating element - Induction heating
Dimension of 4th heating element (mm) - 210 mm
Power of 4th heating element (kW) - 2.2 kW
Power on indicator - No
Type of lid - Without
Ignition system - No
Main on/off switch - Yes
Safety device - childproof lock, Key Lock, pan recognition, Power management function, Safety time-switch-off
Installed depth - 51.0 mm
INS-Enclosure in production - Dutch, English, French, German, Italian, Portuguese, Russian, Spanish
Type of appliance width - 60
Design - line - Facette fro+rear,side profiles
Electronic After-sales Service - No
induction cooking zone - Yes
Connecting cable type - 1-phase, 2-phase
heating with booster - All
EAN Barcode - \\\'!2E20AC-hdgfih!
