Design
Range - Ceramic Hobs
Approx. width (mm) - 600
For exact product or building in dimensions, please refer to the operating instruction manual and building-in guide.
Ceramic - Yes
Width of appliance (mm) - 574
Depth of appliance (mm) - 504
Cut out width (mm) - 560±2
Cut out depth (mm) - 490±2
Casing depth (mm) - 38
Casing depth with connection box (mm) - 47
Space behind hob - 50
Space to wall or tall unit at side of hob - 50
Stainless steel rim - Flat
Tempered glass - Yes
Controls
Direct Selectio - Yes
Intuitive touch controls located at the front of the hob.
Touch sensor controls - Yes
No. of power levels - 9
Cooking zones
No. of cooking zones - 4
Front left size - 18cm
Vario zone - Yes
Front left output (kw) - 1.8
Front right size - 14.5cm
Front right output (kw) - 1.2
Rear left size - 14.5cm
Rear left output (kw) - 1.2
Rear right size - 12/21cm
Rear right output (kw) - 1.2/2.9
Features
ExtraSpeed - Yes
Timer - Yes
Minute minder - Yes
Auto heat-up - Yes
Safety features
Safety switch-off - Yes
Overheating protection - Yes
Automatic switch off for spillages - Yes
Residual heat indicators - Yes
System lock - Yes
Safety lock - Yes
Stop and Go - Yes
Con@ctivity enabled - Yes
Accessories
Glass scraper - Yes
Electrical connection
Voltage (v) - 230-240
Rated load (kw) - 7.1
Fuse rating - 30
Mains interference suppressed - Yes
Radio/TV suppressed - Yes
Operating/Installation instructions - Yes
