Miele DA5796W Next Step Wall Mounted Cooker Hood with Con@ctivity 2.0
SKU: DA5796W
This product is discontinued and no longer available to purchase.
We regularly check prices against major UK retailers including Argos, Currys, John Lewis and Hughes to stay competitive. If you find the same product cheaper at an authorised UK retailer, we'll do our best to match it. See full details here.
2 year manufacturer warranty
Further details can be found on our delivery information page.
Key Features
• Wall mounted Cooker Hood • Con@ctivity 2.0 • 3 power levels • 893mm wide • 620 m3/h on booster • Stainless steel grease filter • LED lighting • A+ energy rating
• Wall mounted Cooker Hood
• Con@ctivity 2.0
• 3 power levels
• 893mm wide
• 620 m3/h on booster
• Stainless steel grease filter
• LED lighting
• A+ energy rating
| Construction type | |
|---|---|
| Wall mounted cooker hood |
•
|
| Design | |
| Colour |
Stainless steel
|
| RAL colours available as customisation on request |
•
|
| Customisation possible on request |
•
|
| Variable height available as customisation on request |
•
|
| Operating modes | |
| Type of air guide |
Convertible
|
| User convenience | |
| Electronic controls |
•
|
| Light-touch switches with LED |
•
|
| Power levels (number without Booster level) |
3
|
| Booster level |
•
|
| Programmable Booster level switch-off |
•
|
| Run-on time 5 / 15 min. |
•
|
| Grease filter saturation indicator programmable |
•
|
| Active charcoal filter saturation indicator programmable |
•
|
| Silence package |
•
|
| Cleaning convenience | |
| Easy-to-clean canopy interior – CleanCover |
•
|
| Efficiency and sustainability | |
| Energy efficiency class (A++ – E) |
A+
|
| Annual energy consumption in kWh/year |
29.9
|
| Fluid dynamic efficiency class |
A
|
| Lighting efficiency class |
A
|
| PowerManagement system |
•
|
| ECO package |
•
|
| Appliance networking | |
| Miele@home |
•
|
| MobileControl |
•
|
| Automatic function Con@ctivity 2.0 |
•
|
| Filter system | |
| Number of dishwasher safe stainless-steel grease filters (10-ply) |
2
|
| Lighting | |
| LED |
•
|
| Light intensity in Lx |
500
|
| Colour temperature in K |
3,500
|
| Fan | |
| Dual-action fan |
•
|
| ECO motor (DC motor) |
•
|
| Air throughput with max. duct diameter in extraction mode (not for external version) | |
| Air throughput in Level 1 (m³/h) according to EN 61591 |
220
|
| Air throughput in Level 2 (m³/h) according to EN 61591 |
300
|
| Air throughput in Level 3 (m³/h) according to EN 61591 |
400
|
| Air throughput in Booster level (m³/h) according to EN 61591 |
620
|
| Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 |
40
|
| Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 |
48
|
| Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 |
55
|
| Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3 |
64
|
| Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 |
25
|
| Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 |
33
|
| Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 |
39
|
| Sound power in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13 |
49
|
| Air throughput in recirculation mode | |
| Air throughput in Level 1 (m³/h) according to EN 61591 |
150
|
| Air throughput in Level 2 (m³/h) according to EN 61591 |
240
|
| Air throughput in Level 3 (m³/h) according to EN 61591 |
320
|
| Air throughput in Booster level (m³/h) according to EN 61591 |
430
|
| Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 |
52
|
| Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 |
60
|
| Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 |
66
|
| Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3 |
73
|
| Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 |
37
|
| Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 |
45
|
| Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 |
50
|
| Sound power in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13 |
58
|
| Safety | |
| Safety switch-off |
•
|
| Single pane tempered glass |
•
|
| Technical data | |
| Overall height for extraction mode and external mode cooker hoods in mm |
660
- 980
|
| Overall height for recirculation mode cooker hoods in mm |
790
- 1,110
|
| Canopy width in mm |
893
|
| Canopy height in mm |
34
|
| Canopy depth in mm |
520
|
| Minimum height above electric hobs in mm |
450
|
| Minimum height above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm |
650
|
| Net weight in kg |
22.0
|
| Length of supply lead in m |
1.5
|
| Standard plug fitted |
•
|
| Total rated load in kW |
0.10
|
| Voltage in V |
230
|
| Fuse rating in A |
10
|
| Number of phases |
1
|
| Installation notes | |
| Extraction ducting connection at top |
•
|
| Extraction connection at top and rear |
•
|
| Diameter of extraction ducting connection in mm |
150
|
| Telescopic chimney |
•
|
| Standard accessories | |
| Non-return flap |
•
|
| RF Con@ctivity 2.0 communication stick for KM |
XKS 3000 Z
|
